Start by identifying each wire and its corresponding function. The ground wire is typically black and connects to the vehicle’s chassis to provide a ground connection. The tail light wire is usually brown and controls the rear running lights. The brake light wire is red and activates the brake lights when you press the brake pedal. The turn signal wire is typically green or yellow and controls the turn signals on your vehicle.

Once you have identified each wire, follow the wiring diagram to connect them to the appropriate terminals on your tail lights. Make sure to secure each connection with electrical tape or wire connectors to prevent any loose connections. Once you have completed the wiring process, test your tail lights to ensure they are functioning correctly before hitting the road.

By following a 4 wire tail light wiring diagram, you can easily install new tail lights on your vehicle and ensure they work properly. With clear instructions on how to connect each wire, you can complete the installation process with confidence and enjoy the benefits of upgraded tail lights on your vehicle.

So, if you are in need of a 4 wire tail light wiring diagram for your vehicle, be sure to follow the instructions carefully and consult with a professional if you have any questions. With the right guidance, you can successfully wire your tail lights and stay safe on the road.

Download and Print 4 Wire Tail Light Wiring Diagram Listed below
